Test and Measurement Accessories

Bias Tee
Product ImageEP Part NumberFrequency (GHz)Insertion Loss (dB)VSWRPower (W)DC Current (mA)DC Voltage (V)Temperature (C)ConnectorDatasheet


EPBT-4000-SMF-00120 MHz ~ 8GHz0.5 typical< 1.52024050-54 to + 85SMA – male /female



EPBT-250-SMF-001100 KHz ~ 500MHz0.5 typical< 1.52017050-54 to + 85SMA – male /female



EPBT-12000-SMF-00130 MHz ~ 24GHz< 0.8< 1.52050025-54 to + 85SMA – male /female



EPBT-6450-SMF-001200 MHz ~ 12.7GHz< 0.8< 1.32024050-54 to + 85SMA – male /female


ProbePads 05
ProbePads 05

DC – 26.5GHz, CPWG to microstrip transition/adapter for on-wafer microwave measurements, microwave integrated circuits and device characterization.

Highlights

  • DC – 26.5GHz
  • Wire bondable Au contacts
  • Eutectic, epoxy, or solder die attach
  • 99.6% Alumina
  • Thin-film process
Datasheet
RF Package
SMA Package

SMA Package

This precision machined RF package has excellent RF performance to 6GHz.

Highlights

  • High Performance up to 6GHz
  • Low Loss
  • VSWR 1.2:1
  • Precision SMA connector
Datasheet
Transmission Lines

TL99-KIT

Designer’s Kit Part Number: TL-99

Material: Alumina (Al2O3) 99.6%
Thicknesses: 0.005, 0.010, 0.015, 0.020 in.
Lengths: 0.050, 0.100, 0.150, 0.250 in.
Qty: 5 of each Thickness/Lengths (80 pcs Total)



All kits are 100% visual inspected and are shipped in waffle packs.

TLQZ-KIT

Designer’s Kit Part Number: TLQZ-KIT

Material: Quartz (SiO2)
Thicknesses: 0.005, 0.010, 0.015, 0.020 in.
Lengths: 0.050, 0.100, 0.150, 0.250 in.
Qty: 5 of each Thickness/Lengths (80 pcs Total)



All kits are 100% visual inspected and are shipped in waffle packs.
